MIXER
Used to mix cement mixtures, mortars with a plastic consistency, clays, ceramic mixtures etc. The mixer provides for both planetary and rotary mixing rotation.
Laboratory oven built with a steel structure painted in fire at 180 ° C with paints scratch-resistant epoxy.
Thermal insulation is provided in ceramic fiber and low-density refractory bricks.
For the CVK-N and CVK-N / S models, the heating parts are composed of Kanthal-type spiral-wound electric resistors.
For the CVK-N / SCS model the heating parts are composed of silicon carbide electric resistors.
With this oven, it is possible to simulate the entire cooking curve of a continuous industrial oven.
Oven equipped with an easily settable control panel.
Various models available (firing volume and maximum temperature).
Laboratory ovens suitable for cooking with rapid cycles.
The temperature and cooking cycle are controlled by a microprocessor programmer mod. K1PX with which it is possible to set 4 cooking cycles composed, each, of 8 STEPS.
Optional: Indirect forced cooling with automatic chimney control included
Optional: Direct forced cooling with automatic chimney control included
Optional: Automatic chimney management
Optional: Automatic management of the controlled atmosphere
Optional: Automatic vacuum management (Vacuum pump included)
Optional: PC management software (PC excluded)
Various models available (firing zone size and maximum temperature).
Water veil cabin in stainless steel with water recirculation dust suppression system.
Useful working width: 97 × 70 cm in depth.
0.5 Hp water recirculation pump.
Complete with settling tank for recirculation and waste water disposal.
Power supply 400 V three-phase, 50 Hz.
Laboratory instrument suitable for carrying out tests according to the P.E.I method, European Standards, Standard EN154, on three samples simultaneously.
For a professional view of the test result, we recommend the combination with the PEIBOX/B cabin.
