STAND ALONE HALOGEN SET AL
TECHNICAL SHEET Stand-alone halogen set for screen exposing in combination with the proper pneumatic press. DESCRIPTION AND TECHNICAL FEATURES: The halogen set is available as 2000/5000 W or 3500/7000 W The replacement of the halogen bulb, when needed, is very easy. During normal production, the lamp remains ON all the time at the maximum power, depending on the model. The halogen lamp is equipped with a parabolic reflector for the uniform distribution of light. Timer for programs and memorization of exposing time. Power: 400 V–50 Hz (3 phases +earth) – 10000 W, with a possible variation on demand. ACCESSORIES AND RECOMMENDED SPARE PARTS: – Lamp holder carriage. – Lamp support with a resting table for the generator. – Light integrator to compensate for the exhaustion of the halogen bulb in time. – Halogen bulb 5000 o 7000 W depending on the model.
|
CODE |
NAME |
MODEL |
LAMP POWER W |
|
AQSIMPAL5 |
HALOGEN SET 5000 W CAREENED |
AL-5 |
2000/5000 |
|
AQSIMPAL7 |
HALOGEN SET 7000 W CAREENED |
AL-7 |
3500/7000 |
|
AQSRINTEGR |
LIGHT INTEGRATOR WITH PHOTOCELL |
||
|
AQSCARIMPAL |
LAMP HOLDER CARRIAGE |
Seedex polymerizer kiln with drawers is used for drying photosensitive emulsion at a low temperature (30-35°C) or for hardening or polymerizing ( after having applied a proper chemical hardener ) at a higher temperature (55 – 65°C).
TECHNICAL FEATURES
Strong varnished steel structure;
Operating with hot air fan-driven;
Maximum operating temperature 100°C;
Temperature control by a thermostat with digital display;
Sliding drawers on bearings;
4 or 6 drawers standard versions
(other models or dimensions could be available on request)
Upper supporting surface in laminate wood;
Electric power supply: 380 V – 3 phases + earth -50 Hertz
Installed power 9 kW
RECOMMENDED SPARE PARTS
Timer for automatic start and stop
Heating elements
RECOMMENDED HARDENER
Gelhard HD
|
CODE |
NAME AND MODEL |
NUMBER OF DRAWERS |
USEFUL DRAWER SIZE CM. |
OVERALL DIMENSION CM. |
|
AQSFES4073110 |
DRYER KILN FE-4 |
4 |
73 X 110 |
120 X 085 X H115 |
|
AQSFES4093124 |
DRYER KILN FE-4 |
4 |
93 X 124 |
144 X 105 X H115 |
|
AQSFES4103140 |
DRYER KILN FE-4 |
4 |
103 X 140 |
160 X 115 X H115 |
|
AQSFES4123164 |
DRYER KILN FE-4 |
4 |
123 X 164 |
185 X 135 X H115 |
| AQSFES4140180 |
DRYER KILN FE-4 |
4 |
140 X 180 |
200 X 155 X H115 |
| AQSFES4150250 |
DRYER KILN FE-4 |
4 |
150 X 250 |
270 X 165 X H115 |
| AQSFES6073110 |
DRYER KILN FE-6 |
6 |
73 X 110 |
120 X 085 X H135 |
| AQSFES6093124 |
DRYER KILN FE-6 |
6 |
93 X 124 |
144 X 105 X H135 |
| AQSFES6103140 |
DRYER KILN FE-6 |
6 |
103 X 140 |
160 X 115 X H135 |
| AQSFES6123164 |
DRYER KILN FE-6 |
6 |
123 X 164 |
185 X 135 X H135 |
| AQSFES6140180 |
DRYER KILN FE-6 |
6 |
140 X 180 |
200 X 155 X H135 |
| AQSFES6150250 |
DRYER KILN FE-6 |
6 |
150 X 250 |
270 X 165 X H135 |
Made by painted stainless steel, with manual closing clamps.
All movements are effected by 2 driving handwheels plus the beam’s one;
Complete of n ° 3 pression bars and all accessories.
The TME “multistretcher” is a mesh tensioning unit for the professionals.
It allows stretching mesh on many frames of different formats and profiles at the same time.
The waste of mesh is minimized and the most economical production is guaranteed.
The frames can be stretched straight or at any angle with synthetic mesh, metallised polyester as well as stainless steel mesh to produce reproducible stencils for all printing purposes.
Due to the handwheels and beam movements of all 3 sides, a parallel, even mesh tension of warp and weft is guaranteed; the uniform stretching over the entire area is maintained by the clamps on all three sides which are riding independently on roller bearings.
Frame contact with the mesh again is manually driven for easy handling.
| CODE | NAME | MODEL | USEFUL FRAME SIZE CM. | OVERALL DIMENSION CM. |
| AQSTME1330PM | MANUAL STRETCHING MACHINE | TME 130X300 |
130X300 |
390X186XH112 |
|
AQSTME1630PM |
MANUAL STRETCHING MACHINE |
TME 160X300 |
160X300 |
390X216XH112 |
|
AQSTME1830PM |
MANUAL STRETCHING MACHINE |
TME 180X300 |
180X300 |
390X236XH112 |
|
AQSTME2030PM |
MANUAL STRETCHING MACHINE |
TME 200X300 |
200X300 |
390X256XH112 |
The Seedex coating machine is cost efficient, ideal for smaller size frames for universal printing applications.
The infinitely adjustable speed, the extremely smooth movement of the coating carriage and the possibility of selecting the number of coating passes either side will result in depositing reproducible amounts of emulsion for perfect stencils. The Seedex coating machine grants a perfect reproducibility of the coating layer structure coating tolerance +/- 1 micron.
DESCRIPTION
Very user-friendly
Supplied with a full touch screen panel
Adjustable stepless speed
Coat build up from one or two sides
The CPU can store 50 different customized programs
The cross beam can be adapted simply to the required frame format
The machine is supplied installed and is supplied with a pair of coating troughs (length according to desire)
TECHNICAL DATA :
Electrical connection: 230 V – 50/60 hz (other voltage on request)
Pneumatic connection: 6 bar
Control: maintenance-free compact control (SPS) with touch screen panel language change-over by push a button
OPTIONS :
lower frameholder movable
double coating with one clamp per frame
double coating with two clamps per frame
|
CODE |
NAME |
MODEL |
USEFUL SIZE CM |
|
AQSPEM1515 |
AUTOMATIC COATING MACHINE |
SP-B 1515 |
150X150 |
|
AQSPEM1520 |
AUTOMATIC COATING MACHINE |
SP-B 1520 |
150X200 |
|
AQSPEM1525 |
AUTOMATIC COATING MACHINE |
SP-B 1525 |
150X250 |
Frames made of aluminum and iron in different sizes and with different profiles (normal and “German type”).
